I. Overview:

The purification workbench is a vertical laminar flow type local air purification device that provides a sterile clean working environment. The equipment adopts all-stainless steel plate structure, which consists of upper air supply body and lower support cabinet. The surface is baked and the variable air volume fan is used. By adjusting the fan working condition, the wind speed of the purification working area is kept within the ideal range. The air flow surface of the air supply body of the device is provided with an illumination fluorescent lamp and an ultraviolet germicidal lamp. For the convenience of the operator, the operation panel of the purification work area is made of transparent plexiglass, and an observation window is provided, and the support cabinet is available for the operator. Store a variety of tools and materials.

Second, the working principle:

1. The indoor air is pressed into the static pressure box by the multi-wing forward adjustable fan through the pre-filter, and then extruded through the high-efficiency air filter to enter the working area at a uniform cross-section wind speed, and the dust in the working area is blown out at work. A high-clean working environment is formed in the area.

2. The high efficiency air filter has extremely high filtration efficiency for bacteria, so the air sent to the work area is sterile dust-free air, thus forming a sterile environment in the work area.

3. The ultraviolet germicidal lamp installed on the diffuser plate of the wind surface can effectively kill the bacteria remaining in the working area.

Third, technical parameters:

model

SW-CJ-1D

Cleanliness

Level 100 @≥0.5μm (US Federal 209E)

Number of colonies

<0.5 pcs/dish. (diameter 90mm culture plate)

noise

≤62dB(A)

average wind speed

0.25-0.45m/s

Vibration half-peak

≤0.5μm (X·Y·Z)

Illuminance

≥300LX

power supply

AC, single phase 220V/50HZ

Maximum power consumption

300W

weight

85KG

Working size

700*500*520mm

Dimensions

850*580*1600mm

High efficiency filter specifications and quantities

695*460*38*1

Fluorescent / UV lamp specifications and quantities

8W*1/10W*1

Fourth, use:

1. This equipment should be used in an environment with a cleanliness of not less than 10,000.

2. The equipment should be cleaned and the number of colonies detected before use. When it is confirmed that the two indicators meet the technical parameters, they can be used.

3. After the power is turned on, press the switch button shown on the control panel to operate. The air volume adjustment button is used to change the air volume of the air supply. The air volume can be adjusted to a larger position before the work, and the small air volume can be adjusted as needed until the desired wind speed is reached.

4. After the fan is started, the equipment should be self-cleaned for 10 to 20 minutes to start working. When self-cleaning, the ultraviolet germicidal lamp should be turned on to sterilize the working area. When working, the switch can be turned to the lighting position.

5. After the work is finished, the power should be cut off.

V. Maintenance:

1. Regularly check the purification efficiency of the work area, the number of colonies, and the wind speed in the work area (usually three to six months).

2. When it is found that the wind speed becomes small, first check whether the surface of the pre-filter is black. If it is black, the pre-filter has more dust and the resistance is increased. That is, the non-woven fabric in the pre-filter should be removed for cleaning or Exchange.

3. When the non-woven fabric is exchanged or cleaned, the wind speed cannot be increased, indicating that the high-efficiency filter resistance is increased. At this time, the air volume button can be adjusted to increase the air volume of the fan, thereby increasing the wind speed of the air supply surface.

4. When the air volume adjustment button is adjusted to the maximum but still can not increase the wind speed, it means that the high efficiency filter has been completely blocked, and the high efficiency air filter must be replaced.

5. When replacing the high-efficiency air filter, pay attention to the correct type of high-efficiency air filtration, and recognize the arrow mark on the high-efficiency filter. The arrow should point in the direction of air flow.

6. After the high-efficiency air filter is replaced, it is necessary to confirm that the frame is not leaking. And carry out system testing, and then reach the technical indicators before normal work can be carried out.

7. Regularly check the electrical circuit. If there is any fault, it should be eliminated in time.
